Wire Drawing Line (φ0.5mm-φ1.2mm) -
- Number of Drawing Dies: up to 21
- Inlet Wire Diameter: 2.6mm - 3.0 mm
- Finished Wire Diameter: 0.5 mm - 1.2mm
- Drawing Cone: 4
-
Intermediate Wire Drawing Line (φ0.10mm-φ0.40mm) -
- Number of Drawing Dies: up to 24
- Inlet Wire Diameter: 0.55mm - 1.2 mm
- Finished Wire Diameter: 0.10 mm - 0.40mm
- Drawing Cone: 4
-
Auto Fine Wire Drawing Machine and Dies (φ0.10-φ0.40mm) -
- Number of Drawing Dies: up to 24
- Inlet Wire Diameter: 0.55mm - 1.2 mm
- Finished Wire Diameter: 0.10 mm - 0.40mm
- Drawing Cone: 4
-
Fine Wire Drawing Machine(0.012 mm - 0.025mm) -
- Number of Drawing Dies: up to 12
- Inlet Wire Diameter: 0.018mm - 0.038 mm
- Finished Wire Diameter: 0.012 mm - 0.025mm
- Drawing Cone: 2
-
Superfine Wire Drawing Machine(φ0.0085mm-φ0.013mm) -
- Number of Drawing Dies: up to 10
- Inlet Wire Diameter: 0.0112mm - 0.0174 mm
- Finished Wire Diameter: 0.0085 mm - 0.013mm
- Drawing Cone: 2
-
Customized Wire Drawing Machine -
Dingtian provides precious metal wire drawing line customization service, metal(alloy) type/wire diameter and spooling method are selected by customers for their certain needs.
Changzhou Dingtian Electrical Machinery Co. is a trustworthy manufacturer of highly efficient wire drawing lines. These machines are specially designed to complete drawing, annealing, and spooling functions in wire production. We are constantly striving for improvements in wire drawing technology. When we first began, the minimum finished wire diameter of our equipment was 0.02mm. Now, our machines can produce 0.0085mm diameter wires. We work extremely hard to satisfy the needs of our customers and if you cannot find what you need, contact us and we can provide you with fully customized wire drawing equipment.
